TFT-H035B22WVIST3C30 | 3.5 Inch IPS TFT LCD | MIPI DSI Interface | 480x800 px High Resolution LCD Screen | Capacitive Touchscreen | 3.5” PCAP TFT with 2-lane MIPI DSI | High-Speed Data Transfer | Lower EMI | Reduced Wiring Complexity

This 3.5” IPS TFT LCD display has a high-resolution of 480x800 pixels and built-in EMI shielding. This TFT includes a high brightness LED backlight with a typical luminance rating of 350 nits. This display offers stunning sharpness, superior color reproduction, better image consistency, and high contrast with full viewing angles due to the IPS technology built into this Liquid Crystal Display.

While this transmissive LCD boasts impressive quality with a 3.3V power supply, it also includes a capacitive touch panel, making it an excellent choice for projects that desire high-end visual output with 10-point multi-touch functionality. The Projected Capacitive (PCAP) touchscreen with built-in I2C interface and GT911 controller, will allow users to perform various gestures and interact more intuitively with its precise touch recognition and enhanced responsiveness for interactive applications. The display, powered by a built-in ST7701S driver IC and compatible with Raspberry Pi, delivers exceptional performance and reliability. The driver optimizes the display's functionality, ensuring smooth operation and accurate rendering of images and graphics. This LCD features a FFC (Flat Flexible Cable) connection style, ensuring a hassle-free electrical connection. All of our displays are RoHS compliant and adhere rigorously to environmental and safety regulations.
