1.44 inch IPS display square TFT LCD module 128x128 Arduino display

1.44 inch IPS display square TFT LCD module 128x128 Arduino display

▶ Model: LCM-TFT014T1QQS4LN08D

▶ Type: TFT module
▶ Display pixels: 128x128 Px
▶ Overall dimensions (mm): 30x46.5x11.3
▶ Display inches: 1.44"
▶ Effective size (mm): 25.5x26.5
▶ Application: Printer
▶ Viewing angle: 12H
▶ Brightness: 400cd/M²
▶ Pin: 8 PIN
▶ Interface: SPI
▶ Special instructions: Anti-static ESD 8KV
▶ Working temperature: -20~70℃
▶ Power supply voltage: 3.3V
▶ Driver chip: ST7735S

Product Consultation Datasheets Download Demo Code
- Transportation
- Payment
- Taxes
- Ensure
- Return
- Discontinued
Transportation

Our company cooperates with SF Express for domestic express delivery, and DHL for overseas express delivery. You can contact us to inquire about freight and weight to get the latest quotation.

Payment

Online payment is not supported. Transfers can be made through corporate accounts. If a VAT invoice is issued, please contact our sales staff to obtain a corporate account.

Taxes

All products sold on this website do not include tax. If you need a VAT invoice, please contact our sales staff to purchase offline.

Ensure

All products sold on this website have a one-year warranty. If the product is damaged due to improper use by the customer, it will be repaired free of charge. Material cost will be charged.

Return

Products within the warranty period can be returned for repair or replacement. Before returning, please contact our sales staff to confirm the reason for return.

Discontinued

We are committed to long-term production of all products sold on this website. If the IC or panel is discontinued, we will try our best to replace it with compatible materials.

No Back Next

Product Description
Specification
Attributes
Download Related Materials

LCM-TFT014T1QQS4LN08D | 1.44" square LCD module | 128x128 pixels | Serial SPI interface | 8-pin FFC ZIF connection | With driver control board | Optional capacitive/resistive touch screen | Arduino display

This 1.44" square LCD module is an embedded display solution designed for projects that need to display high-quality, colorful images. Featuring a resolution of 128x128 pixels and a bright LED backlight with a brightness of 400cd/M², it Providing clear and vivid images in a variety of environments. Using Multi-Domain Vertical Alignment (MVA) technology, the display still provides excellent clarity at viewing angles of up to 70°, ensuring that users can see clearly at different angles. Get a stunning visual experience. Its compact size, 3.3V power supply, and design without a touch screen make it an ideal choice for vertical mode visual output projects.

Equipped with a 4-wire serial SPI interface, the communication efficiency with C8051, Arduino, STM32 and other devices is particularly optimized. Users can experience lightning-fast data transfer and real-time updates, resulting in smoother animations and more dynamic visual effects. Powered by the ST7735S controller, which not only optimizes the monitor's functionality but also ensures smooth operation and accurate rendering of images and graphics.

In addition, our displays are RoHS compliant and strictly adhere to environmental and safety standards. Whether used in embedded systems, industrial equipment, security devices or handheld devices, this TFT display delivers superior performance and reliability to your project.
