Hot Display Technology early April 2024 Focus Information

E-Newsletter Issue 1

Welcome to read the early April 2024 edition of Xinhongtai E-Newsletter!

This month we are happy to show you our latest display products, which have high resolution, rich colors, moderate brightness, high cost performance, different levels of size, strong selectivity and so on! Let's embark on a journey of exploration and discovery together to learn all the details!

Recommended products in this issue:

1、0.96~2.8 inch mini LCD display

▶ Module: TFT-H024A9QVIFT8N20

▶ Type: TFT vertical screen

▶ Display pixels: 240x320 Px

▶ Dimensions (mm): 42.52x59.86x2.20

▶ Display inches: 2.4"

▶ Effective size (mm): 36.72x48.96

▶ Application: Android motherboard/RK motherboard

▶ Viewing angle: IPS (U85/D85/L85/R85)

▶ Read more

▶ Model: TFT-H020A6QVIST6N10

▶ Type: TFT vertical screen

▶ Display pixels: 240x320 Px

▶ Dimensions (mm): 35.7x51.2x2.3

▶ Display inches: 2.0"

▶ Effective size (mm): 30.6x40.8

▶ Application: C8051/Arduino/STM32

▶ Viewing angle: IPS full viewing angle

▶ Read more

▶ Model: TFT-H013C4QQIST3N18

▶ Type: TFT square

▶ Display pixels: 240x240 Px

▶ Dimensions (mm): 26.60×29.60×2.30

▶ Display inches: 1.3"

▶ Effective size (mm): 23.4x23.4

▶ Application: smart wearable, instrumentation

▶ Viewing angle: IPS full viewing angle

▶ Read more

2、2.9~4.9 inch TFT LCD screen

▶ Model: TFT-H040A22DKINV3N30

▶ Type: TFT square screen

▶ Display pixels: 720x720 Px

▶ Dimensions (mm): 74,830x78.98x2.15

▶ Display inches: 4.0"

▶ Effective size (mm): 71.928x71.928

▶ Application: Linux/industrial control/RK

▶ Viewing angle: IPS full viewing angle

▶ Read more

▶ Model: TFT-H035B22WVIST3C30

▶ Product type: TFT capacitive touch module

▶ Dot matrix: 480x800 Px

▶ Dimensions (mm): 56.0(H)x95.0(V)x5.1

▶ Diagonal size: 3.5"

▶ Effective size (mm): 45.36x75.6

▶ Application: Android motherboard/RK motherboard

▶ Display viewing angle: IPS (U85/D85/L85/R85)

▶ Read more

3. 5.0~7.0 inch LCD display:

▶ Model: TFT-H068A05ZAINV5C50

▶Product type: TFT long strip

▶ Display content: 480x1280

▶ Dimensions (mm):73.50x195.39x6.5

▶ AA(mm) ：60.192x160.512

▶ Product application: Instruments

▶ Viewing angle: Full View

▶ Brightness: 500cd/m2

▶ Read more

▶ Model: TFT-H052A01ZAINV5N40

▶ Type: TFT bar

▶ Display pixels: 416x1280 Px

▶ Dimensions (mm): 43.55x131.28x2.10

▶ Display inches: 5.2"

▶ Active size (mm): 40.75x125.38

▶ Application: STM32/RK series

▶ Viewing angle: IPS (U85/D85/L85/R85)

▶ Read more

4. 7.1~15.6 inch TFT LCD display

▶ Model: TFT-H101D13W XIWZKN40

▶ Type: TFT LCD color screen

▶ Display pixels: 1280x800 Px

▶ Dimensions (mm): 229.46x149.1x4.7

▶ Display inches: 10.1"

▶ Effective size (mm): 216.96x135.6

▶ Application: Industrial control equipment

▶ Viewing angle: IPS full viewing angle

▶ Read more

▶ Model: TFT-H080B7HDINV5C30

▶ Type: TFT vertical screen

▶ Display pixels: 800x1280 Px

▶ Dimensions (mm): 124.60x194.10x4 .70

▶ Display inches: 8.0"

▶ Effective size (mm): 107.64x172.224

▶ Application: Industrial computer

▶ Viewing angle: IPS full viewing angle

▶ Read more

For more TFT related products, please click this link: TFT Color LCD Display
